Liquid Fuel Delivery Units

WITH A CUSTOMIZED DELIVERY UNIT BUILT AND SERVICED BY GROWMARK TANK & TRUCK CENTER, YOUR OPERATION CAN KEEP MOVING FORWARD, FULL SPEED AHEAD.

Specs are established around your specific needs to give maximum productivity. Tank and product weights are analyzed to ensure compliance with state and federal weight limits and to comply with manufacturer weight ratings.

Clutch-Pak PTO’s and Blackmer Pumps with underframe mounting drive the pumping systems. Hydraulic power is also available along with remote pump placement. Dual pumping systems are designed to maximize flow rates and equipment longevity. The pumping system includes strainers and optional filters - especially needed in bio-fuel applications.

LC Meters and the LCR2 electronic registers give ultimate flexibility in metering varying products, and accurately measuring deliveries with little maintenance cost. Multiple pricing and tax levels can be maintained and presets allow specific delivery amounts.



  • Standard Specifications
  • Optional Specifications

Standard Specifications

  • Boston Tanks 2700 to 5500 gal. in various configurations
  • Aluminum barrel carrier box 66” (one side)
  • Blackmer pumps (2ea TXSD 2-1/2” )
  • LC Meters (2ea. M-7-C-1 w/ LCR2’s and presets)
  • Hannay electric hose reels (2 ea. Side discharge)
  • 75’ Hose x 1-1/4” street side
  • 125’ Hose x 1-1/4” curb side
  • Clutch pack PTO's
  • Air operated compartment valves eliminates cable stretching

Optional Specifications

  • 1-3/8” hose in lieu of 1-1/4”
  • Work lights
  • Flush tank
  • 6” Aluminum hose tube
  • Air operated, dual manifold
  • Bottom load
  • Express drop w/2” x 20’hose
  • Rear vision camera system
  • Product identification cards with holders
  • Catwalks
